Fabtech 11-19 GM 3500HD 2WD/4WD 6in Rts Sys w/Perf Shks - K1051

Part Number: FABK1051

Your Price:
$2,872.67 $2,585.39
(You save $287.28)
Write a Review
Availability:
Special order
MPN:
K1051
Photo - Primary

Product Information

Fabtechs cutting edge RTS(TM) system has now been developed for the all new GM HD platform. The 6 RTS(TM) utilizes a patent pending bracket system that keep the torsion bars raised up, in the stock location. This feature provides superior ground clearance at the frame as there are no torsion bars hanging down to become high centered on or damaged when offroading.. The 6 RTS(TM) system has been designed with unitized bracketry to retain the four front compression stops of the vehicle as GM intended. This distributes impact loads across a wide section of the frame rather than at a single point.High arched crossmembers and front differential skid plate are constructed of 1/4 thick steel to resist bending from hard front suspension impacts. Only 1/4 thick steel provides the rigidity and strength necessary to relocate the torsion bars, bump stops and lower control arms properly. Minimal heavy duty bracketry allow for a fast installation time with only two holes to drill and no cutting of the front diff housing. The 6 RTS(TM) system allows the use of both 18 and 20 diameter wheels.

This Part Fits:

YearMakeModelSubmodel
2015-2018ChevroletSilverado 2500 HDHigh Country
2014-2018ChevroletSilverado 2500 HDLT
2014-2018ChevroletSilverado 2500 HDLTZ
2014-2018ChevroletSilverado 2500 HDWT
2015-2019ChevroletSilverado 3500 HDHigh Country
2011-2019ChevroletSilverado 3500 HDLT
2011-2019ChevroletSilverado 3500 HDLTZ
2011-2019ChevroletSilverado 3500 HDWT
2015-2018GMCSierra 2500 HDBase
2014-2018GMCSierra 2500 HDDenali
2014-2018GMCSierra 2500 HDSLE
2014-2018GMCSierra 2500 HDSLT
2014GMCSierra 2500 HDWT
2015-2018GMCSierra 3500 HDBase
2011-2018GMCSierra 3500 HDDenali
2011-2018GMCSierra 3500 HDSLE
2011-2018GMCSierra 3500 HDSLT
2011-2014GMCSierra 3500 HDWT
